STRIP / ROLL ADHESIVE COATER & AQUEOUS LAMINATOR (Plain / Window / Perfector(Double Side in Single Pass)
Salient Features :
- Strip and Roll gumming - Roll to roll & Roll to sheet form.
- Independent variable speed drive for coating & lamination
- Heavy duty reel stand with brakes & web lateral adjustment.
- IR Heaters with individual thermostat controls for optimal energy management
- Strip / Plain / Window & Perfector (Double side in Single Pass) Lamination
- Adhesive pan lifting mechanism for window lamination & adhesive coating
- Al. rollers for web traverse inside drying tunnel.
TECHNICAL SPECIFICATIONS
| Feeding | Manual |
| Paper Stock | 90 - 450 g/m² |
| Laminating Speed (Aqueous) | 0 - 45 m/min* |
| Adhesive Coating speed | 2500 - 3000 sheets / hour (18” X 23”)** |
| Laminating Pressure | Mechanical |
STANDARD SIZE :
| MM | 600 | 800 | 900 |
| Inches | 24" | 32" | 36" |
*Production speed is subject to substrate and operating parameters
** Production speed is subject to substrate and operating parameters
